Comfortmaker RAV036H0FA0AAA 3 Ton 11.7 EER Packaged Air Conditioner, 208-230V/3-Phase/60Hz, R-410A
The Comfortmaker RAV036H0FA0AAA is a 3-ton packaged air conditioner built for light-commercial rooftop and ground-mount applications where a single self-contained cabinet is preferred over a split system. It is rated at 11.7 EER and runs on R-410A refrigerant. Factory-charged and tested, it ships ready for a single-point power and duct connection.
Key specifications include a scroll compressor, 208-230V 3-Phase 60Hz power.
Confirm cooling load, electrical service, and duct static against the submittal and local code before ordering. Curbs, economizers, and controls are sold separately.
Specifications
| Nominal Capacity (Tons) | 3 |
| SEER | 14 |
| EER | 11.7 |
| System Type | Straight Cool |
| Refrigerant | R-410A |
| Voltage | 208-230 VAC |
| Phase | Three |
| Airflow (CFM) | 900, 1500 |
| Compressor | Scroll |
| Airflow Direction | Convertible |
| ENERGY STAR | No |
| Cabinet Color | Gray |
| Certifications | UL Listed |
Why Comfortmaker
Comfortmaker is built by International Comfort Products, a Carrier company. These units carry a limited parts warranty; registration is required for maximum coverage and commercial-application terms are defined on the model's warranty certificate. UL Listed listed.
