ALLIED 1.603371 4 Ton 13.4 SEER2 Packaged Gas/Electric Unit, 208-230V/1-Phase/60Hz, 108,000 BTU Heat, R-410A
The ALLIED 1.603371 is a 4-ton packaged gas/electric unit built for residential rooftop, slab, or ground-mount applications where a single self-contained cabinet is preferred over a split system. It is rated at 13.4 SEER2 and runs on R-410A refrigerant. Factory-charged and tested, it ships ready for a single-point power and duct connection.
Key specifications include integrated gas heat rated at 108,000 BTU input, 208-230V 1-Phase 60Hz power.
Confirm cooling load, electrical service, and duct static against the submittal and local code before ordering. Curbs, economizers, and controls are sold separately.
Specifications
| Nominal Capacity (Tons) | 4 |
| SEER2 | 13.4 |
| EER2 | 10.6 |
| System Type | Gas Electric |
| Refrigerant | R-410A |
| Voltage | 208-230 VAC |
| Phase | Single |
| Heating Input (BTU) | 108000 |
| Airflow (CFM) | 490, 1775 |
| Airflow Direction | Multi-Position |
| ENERGY STAR | No |
| Cabinet Color | Gray |
| Certifications | AHRI Certified, ETL Listed |
Why ALLIED
ALLIED HVAC equipment. AHRI Certified, ETL Listed listed. See the model's warranty certificate for coverage terms.
